Development Resources and Other Options
Providing Comprehensive System Solutions
CAN/LIN Development Tools
With easy-to-use development systems and application
notes, Microchip provides a total CAN/LIN solution that
enables low-risk product development, lower total system
cost and faster time to market for high performance
embedded designs.
LIN Serial Analyzer Development System (APGDT001)
CAN BUS Analyzer (APGDT002)
The LIN and CAN analyzer development
tools enables a PC to communicate
with the LIN and CAN buses. The PC
program uses a graphical user interface
to enter and display message frames
occurring on the?target bus, allowing for
easy debug. The tools can also be used
as an active node on a bus to send and
receive messages, therefore reducing
the application development time.
CAN/LIN PICtail Plus Daughter Board (AC164130-2)
This daughter board can be used with
the Explorer 16 Development board and
various PIMs featuring 16- and 32-bit
MCUs with CAN peripherals, or the PIC18
Explorer board with the PIC18F66K80
PIM to facilitate rapid implementation and evaluation of
CAN and LIN applications.
PICkit 28-pin LIN Demonstration Board (DM164130-3)
The PICkit 28-pin LIN demo board enables
a quick start in developing and debugging
applications with the LIN drivers. The kit
includes a 28-pin socket which supports
various PIC16F devices, includes a LIN
transceiver, plus a generous prototype area
with various indicator LEDs and buttons to
support the test and debug of the application.
PICDEM CAN-LIN 3 Demonstration Board
(DM163015)
The PICDEM CAN-LIN 3 demo board is
an easy way to discover the power of
Microchip’s CAN and LIN products. The
board demonstrates the main features of
the 64-pin TQFP PIC18F6680 and 80-pin
TQFP PIC18F8680 devices, including those features of the
integrated CAN module. In addition, the board employs a LIN
sub-network using Microchip's 20-pin SSOP PIC18F1320 and
MCP201 LIN Bus.
LIN Software Library
LIN Data Link Layer firmware can be downloaded
free-of-charge from Microchip’s web site. Many third
party companies also offer LIN Data Link Layer firmware,
providing additional design options.
Other Connectivity Options
While the most sophisticated protocols and interfaces
tend to garner a significant amount of attention, a
number of simpler connectivity options are and will
remain the embedded interconnects of choice for many
deeply embedded applications. Microchip’s focus on the
embedded market ensures an ongoing commitment to
support all of the connectivity solutions utilized by leading
designers, including the microcontroller peripherals,
application notes and software necessary to implement
robust, highly reliable embedded networks.
RS-485 Protocol
The RS-485 protocol is typically used as a more feature-
rich alternative to RS-232. The protocol enables longer
distance between nodes and higher data rates. Any
PIC microcontroller with an on-board UART can support
RS-485 communication. Many PIC microcontrollers include
enhanced peripherals with an RS-485 mode.
IrDA Protocol
The IrDA protocol provides many portable devices with an
affordable, short distance optical data communications
link. IrDA can be implemented on many Microchip MCUs
using Microchip's free-of-charge IrDA software stack. In
addition, Microchip offers UART to IrDA protocol converter
products (MCP2140A, MCP2150) to enable any system to
easily add IrDA wireless connectivity.
IrDA PICtail Plus Daughter Board (AC164124)
Enables IrDA connectivity when used
with the Explorer 16 development board
(DM240001).
MCP2140 Wireless Temperature Sensor
Demonstration Board (MCP2140DM-TMPSNS)
Demonstrates the communication of
temperature data to a primary device (PDA
or PC with IR port) via IrDA.
www.microchip.com/can
Connectivity Solutions
7
